100mm F2.8 APO Macro Elmarit SL
APO-Macro-Elmarit-SL 100 f/2.8
The Leica APO-Macro-Elmarit-R 100 f/2.8 was a milestone in optical craftsmanship when it was released in 1987. To honour this classic lens, Leica
is now introducing the new APO-Macro-Elmarit-SL 100 f/2.8. Like its predecessor, this SL-System macro lens delivers outstanding imaging performance
right to the edges thanks to apochromatic correction.
With a close focus distance of just 30 cm and a maximum reproduction ratio of 1:1, this lens reveals details that are invisible to the naked eye.
It is also ideal for use as a telephoto lens in portrait photography. The nine-blade aperture, in conjunction with the entire optical design, ensures a harmoniously
rendered background. The robust, full-metal L-Mount body is 137.6 mm long and weighs 862 g, including the supplied lens hood.
The front element is protected from external influences by an AquaDura coating, while the E67 filter thread opens up additional creative possibilities.
| Specifications |
|
| View angle: |
|
| Diagonal: |
22.7° Full-frame (24 x 36 mm) |
| Horizontal: |
19.6° Full-frame (24 x 36 mm) |
| Vertical: |
13° Full-frame (24 x 36 mm) |
| Number of lenses: |
17 |
| Number of groups: |
12 |
| Position of the entrance pupil: |
36 mm before the bayonet |
| Focus range: |
0.29 m to 88 |
| Focusing Setting: |
Choose automatic (Autofocus) or manual mode on the camera |
| Smallest object field: |
23.9 mm x 35.9 mm |
| Largest scale: |
1:0.997 |
| Aperture Setting/Function: |
Electronically controlled aperture, setting on the camera, half or third values can also be set |
| Smallest aperture: |
22 |
| Bayonet: |
Leica L bayonet fitting with contact strip |
| Firmware: |
Lens firmware can be updated via the camera |
| Coating: |
Hydrophobic Aqua-Dura® coating on external lens |
| Material: |
Aluminum full-metal housing, black anodized, dust and splash water protected |
| Filter thread: |
E67 |
| Lens hood: |
Male bayonet for lens hood (included in the scope of delivery) |
| Dimensions |
|
| Length: |
Approx. 137 mm/187 mm (without/with lens hood) |
| Diameter: |
Approx. 77 mm/82 mm (without/with lens hood) |
| Weight: |
Approx. 801 g/862 g (without/with lens hood) |
